ASSEMBLY INSTRUCTIONS
21. Attach the offset damper plate (O) to the access
tray (T) using one M6 x 12 bolt (BB) and one
M6 lock nut (FF).
22. Place the charcoal grate (Q) inside the access
tray (T) and slide the tray into the offset smoker box.
22
O
T
21
Q
Hardware Used
BB
M6 x 12mm
Bolt
x 1
FF
M6 Lock Nut
x 1
FF
BB
T
