PACKAGE CONTENTS
A
1
3
5
2
4
8
7
10
9
6
13
14
11
12
15
PART DESCRIPTION QUANTITY
9 Lid Handle & Left/Right
Side Handles 3
10 Upper Support Brackets 3
11 Water Bowl 1
12 Cooking Grate 2
13 Temp Gauge w/ Nut 1
14 Lid Assembly 1
15 Lid Damper Plate 1
16 Dyna-Glo Badge 1
PART DESCRIPTION QUANTITY
1 Lower Damper Plate (L/R) 2
2 Bottom Smoker Section 1
3 Smoker Body Latch 3
4 Ash Pan 1
5 Charcoal Grate 1
6 Lower Support Brackets 3
7 Middle Smoker Section 1
8 Access Door Assembly 1
