Dyna-Glo DGVS390BC - Assembly Instructions; Step 1: Bottom Section Assembly; Step 2: Install Ash Pan and Grate

9
ASSEMBLY INSTRUCTIONS
Step 1
Step 2
1
2
2
4
3
5
Hardware Used
A
M4 x 15 mm
Screw
x 6
1
Parts Used
1
Side Damper
Plate
x 2
2
Bottom Smoker
Section
x 1
3
Smoker Body
Latch
x 3
B
M4 Wingnut
x 6
C
M5 x 12 mm
Shoulder Screw
x 4
D
M5 Wingnut
x 4
D
C
A
B
Parts Used
4
Ash Pan
x 1
5
Charcoal Grate
x 1
