dynabook Portege X30L-K Series - 4.15.2 Installing the Fin

2
3
1
Fin
B2 x 2.5CT
When removing the Fin, be sure to remove the screws in the reverse order of the
number marked on the Fin.
When installing the Fin, be sure to install the screws in the order of the number
marked on the Fin.
Figure 4-10 Removing the Fin
4.15.2 Installing the Fin
To install the Fin, follow the steps below.
1. Set the Fin in place and secure it with the screws.
