Do not reuse the removed screws. Be sure to use new screws.
Take care not to short circuit the terminals when removing the battery pack.
Similarly, do not drop, knock, scratch, disassemble, twist, or bend the battery pack.
Battery Harness
CN8021
Dispose of the used/removed battery pack in accordance with the laws
and ordinances
of your local authority.
4.11.2 Installing the Base Assembly
To install the Base Assembly, follow the steps below.
1. Set the Cover Assembly on the Base Assembly while securing the
latch.
2. Secure the Cover Assembly and Base Assembly with the screws.
3. Turn the computer, and open the display.
4.12 Battery pack
4.12.1 Removing the Battery pack
To remove the battery pack, follow the steps below.
1. Disconnect the BATTERY HARNESS from the connector CN8021 on
the System board.
2. Remove the following screws and the battery pack.
Figure 4-6 Releasing the battery pack
