Operation - Before starting
32 4812325556EN 2017-11-22
Standard operator's seat - adjustment
Adjust the operator's seat so all the controls are within easy
reach and the machine operation is comfortable.
(1) Length adjustment.
(2) Weight adjustment.
(3) Back support adjustment.
(4) Seat belt.
ALWAYS make sure the seat is locked before
starting the operation.
Always use the seat belt (4).
Comfort operator's seat (option) - adjustment
Adjust the operator's seat so all the controls are within easy
reach and the machine operation is comfortable.
(1) Length adjustment.
(2) Height adjustment.
(3) Seat-cushion inclination.
(4) Back support inclination.
(5) Armrest inclination.
(6) Lumbar support adjustment.
(7) Seat belt.
Fig. - Operator's seat (option adjustment)
