Dynapac LH700 - Machine Dimensions and Accessories; Overall Machine Dimensions; Accessory Dimensions and Weight

12 LH700 ILH700EN1
LH700
A mm (inch) 1880 (74)
B mm (inch) 660 (26)
C mm (inch) 795 (31)
D mm (inch) 1180 (46)
E mm (inch) 1050 (41)
Contact area,
m
2
(sq feet) 0,290 (3,12)
Accessories LH700
Extension plates
Width, mm 2x75=150
2x150=300
Weight, kg 14,6 / 24,6
Contact area, m
2
Width 150: 0,356
Width 300: 0,422
TECHNICAL DATA – DIMENSIONS
B
CONTACT AREA
E
D
A
C
L000436
L000630A
