CONTENTS
WARNING SYMBOLS
WARNING Indicates danger or hazardous
procedure that could result in serious or fatal
personal injury if the warning is ignored.
CAUTION Indicates danger or hazardous proce-
dure that could result in damage to machine or
property if the warning is ignored.
Read through the entire manual before
starting any maintenance operations.
Ensure good ventilation (air extraction) if the
engine is run indoors.
The safety instructions are included in this
manual and must be studied by the operator.
Always follow the safety rules and keep the
manual available for future use.
SAFETY INSTRUCTIONS
WARNING
CAUTION
CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of
its constituents are known to the State
of California to cause cancer, birth
defects, and other reproductive harm.
WARNING
WARNING
WARNING
Page
General ............................................................................ 3
Machine plate ................................................................... 3
Safety instructions (For all Light products).................... 4-6
Safety when driving .......................................................... 7
Safety decals, Location/Description ............................. 8, 9
Fuel and lubricants ......................................................... 10
Technical data ................................................................ 11
Technical data – Dimensions ......................................... 12
Handle position ............................................................... 13
Handle adjustments ....................................................... 14
Control lamps ................................................................. 14
Operation – Hatz 1D90V, El.start............................. 15, 16
Operation ....................................................................... 17
Lifting and transportation ................................................ 18
Lifting .............................................................................. 18
Maintenance – service points .................................. 19, 20
Maintenance – Every 10 hours of operation................... 21
Maintenance – Every 100 hours of operation ................. 22
Maintenance – Every 500 hours of operation ................. 23
Maintenance – Every 1000 hours of operation ............... 24
