12
LP8500 ILP8500EN1
Vibration System
Pump Gear Type
Motor Gear Type
Vibration Frequency 32 Hz (1800 rpm)
Centrifugal Force 65 kN (14600 lbs)
Amplitude 1,2 mm (0,04 in)
Pressure Relief Valve 15 MPa 2175 psi)
Ergonomics
The following sound and vibration levels are determined in accordance with the operating cycle
described by EU directive 2000/14/EC.
Guaranteed acoustic power level
LwA dB (A) 106
Sound-pressure level at the operator’s ear (ISO 6396)
LpA dB (A) 92
Hand and arm vibration (ISO 5349-1)
a
hv
m/s
2–
During operation these values may differ because of the actual operational conditions.
TECHNICAL DATA
