28
LP8500 ILP8500EN1
1. Fill up fuel tank (5) every day use diesel with the
following specifications.
DIN 51 601 - DK
BS 2869 A1 / A2
ASTM 975 - 1D / 2D
Warning! Fire hazard!
When working on the fuel system do
not use open fire, do not smoke, do not
refuel in closed rooms. Dirty fuel can cause
malfunctions or engine damage.
1. Stop the engine an wait for a couple of minutes.
The machine must be in horizontal position.
2. Remove any dirt in the area of the oil dipstick.
3. Check the oil level on dipstick (1), refill oil (2) to
upper mark if necessary.
6
5
1
4
3
2
7
Check the engine oil level
Check hydraulic oil level
Check fuel tank level
Check air cleaner
Check the scraper adjustment
1. Wipe of the oil level gauge (3) and check that the
level is in the middle of the glass. If necessary
fill up (4). If the level is sinking check for leakage.
1. Check air inlet opening clean if necessary
2. Check dust extractor valve (6) for free flow, remove
any blockage by pressing together.
Check connecting hoses and clamps condition.
1. Make sure that every scraper do not touch the pads
on the drums. Adjust if necessary distance
to 3-5 mm (0.1-0.2 in). With screws (7).
MAINTENANCE – EVERY 10 HOURS
L000365A
L000367A
L000368A
L000369A
WARNING
L000629A
