LP8500 ILP8500EN1
TECHNICAL DATA
Weight
Net Weight 1650 kg (3638 lbs)
Operating Weight 1675 kg (3693 lbs)
Performance
Travel Speed 0-4 km/h (0-2,5 mph)
Operating Speed 0-2 km/h (0-1,2 mph)
Brakes
Service Brake Hydrostatic
Parking Brake Mechanical
Capacties
Engine Oil 2,5 lit. (2.1 qts)
Fuel Tank 17,0 lit. (18 qts)
Hydraulic Tank 21,0 lit. (5.6 gal)
Engine
Make/Model Hatz 2G40 2-cylinder diesel
Rated Power 12,5 kW (17,5 hp)
Rated Speed 2500 rpm
Cooling System Air cooled + hydraulic fluid cooler + fan
Air Cleaner Dry Type
Electrical System
Battery voltage 12 V
Battery Capacity 50 Ah
Alternator 330 W
Starter Motor 1,7 kW (2,3 hp)
Steering
Steering System Radio
Temporary with switches on the machine
Traction System
Pump Gear Type
Motors Radial Piston
Pressure valve 26,5 MPa
LP8500
850 mm (33,5 in) wide drums
