14

LP8500 ILP8500EN1

A mm (in) 850 (33)

B mm (in) 535 (21)

C mm (in) 1385 (55)

D mm (in) 1875 (74)

E mm (in) 630 (25)

F mm (in) 850 (33)

G mm (in) 1207 (47)

H mm (in) 630 (25)

TECHNICAL DATA – DIMENSIONES

A

L000339B

B

C

G

L000340B

D

H

E

F

LP8500
