Dynapac SD2550C - Page 111

D 11 25
Item Designation Brief description
48
Left conveyor
"AUTO"
Button with detent switch function and LED feedback:
- The conveying function of the left conveyor is
switched on when the drive lever is swivelled out and
is continuously controlled via the material limit switch-
es in the material tunnel.
- Switch OFF by pressing the button again
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, note danger zones of moving parts of the
vehicle!
49
Right conveyor
"AUTO"
Button with detent switch function and LED feedback:
- The conveying function of the right conveyor is
switched on when the drive lever is swivelled out and
is continuously controlled via the material limit switch-
es in the material tunnel.
- Switch OFF by pressing the button again
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, note danger zones of moving parts of the
vehicle!
