Dynapac SD2550C - Main menu; Displays:

D 21 5
Main menu
Display and function menu
Displays:
- (1) Speed:
- paving operation (m/min)
- driving mode (km/h)
- (2) Actual temperature of
the screen heater (°C)
- (3) Fuel gauge
- (4) Conveyor filling level
left/right
- (5) Distance travelled counter (m)
- (6) Operating hours (h)
- (7) Time of day (hh/mm)
- (8) Used paving parameters from the parameter memory
- (9) Extension distance levelling cylinders left/right (o)
- (10) Error warning (retrievable in the error memory)
- (11) Operating status: different symbols are shown depending
on the operating status:
Hare: Transportation gear active
Tortoise: Working gear active
STOP: Machine stop
20km/h: Important! Machine speed too high! Reduce travel!
Snow flake: hydraulic oil temperature too low! Bring vehicle up to tempera-
ture with stationary acceleration!
A
The engine speed cannot be increased when the hydraulic oil temperature
is too low!
B
C
D
E
F
G
A
7
10
3
1
2
11
5
6
9
4
8
