Dynascan DS551LT7 - Pin Assignments; DVI-D Output Pin Assignments; DVI-D Input Pin Assignments

DS551LT7 User Manual 25
Input Mode
Active Resolution
H Pixels V Lines
Refresh Rate Pixel Rate Aspect Ratio
640 480 60 Hz 25.175 MHz 4:3
50 Hz 27 MHz 4:3
720 480
59.94 Hz 27 MHz 4:3
800 600 60 Hz 40 MHz 4:3
1024 768 60 Hz 65 MHz 4:3
50 Hz
1280 720
60 Hz
74.25 MHz 16:9
1280 768 60 Hz 79.5 MHz 5:3
1360 768 60 Hz 85.5 MHz 16:9
50 Hz
1920 1080
60 Hz
148.5 MHz 16:9
