Tower ESS User Manual
©Dyness reserves the copyright of this document.
9
Figure 2-2 Battery module
Table 2-2 Product parameters
Module name
HV9637
Cell technology
Li-ion (LFP)
Battery module energy (kWh)
3.552
Battery module voltage (V/DC)
96
Battery module capacity (Ah)
37
Number of battery module cells (pcs)
30
Battery cell power (Wh)
118.4
Battery cell voltage (V/DC)
3.2
Battery cell capacity (Ah)
37
Number of battery module cells in series (pcs)
30
Battery module charge voltage (V/DC)
109.5
Battery module charge current (normal) [A]
18.5
Battery module charge current (max) [A]
37
Battery module discharge minimum voltage
(V/DC)
84
Battery system discharge current (standard) [A]
7.4
Battery module discharge current (normal) [A]
18.5
Battery module discharge current (max) [A]
37
Dimensions (W*D*H, mm)
380*504*240
Communication mode
CAN/RS485
Pollution degree (PD)
II
Operating temperature (°C)
0~50
IP protection class
IP54
Weight (kg)
41
