Tower ESS User Manual
10
©Dyness reserves the copyright of this document.
Figure 2-3 HV9637 connections on top
Figure 2-4 HV9637 connections at bottom
Table 2-3 Interface Definition
Name
Definition
Composite connector - Plug
Battery module output and communication
interface
Composite connector - Socket
Battery module output and communication
interface
Figure 2-5 Composite Connector-Plug
Composite
connector - Plug
Composite
connector-Socket
1
1
4
6
3
9
2
2
7
8
5
