Fitting notes
Service manual
28
69 Remove the short screw and
plastic washer holding the
stabiliser assembly onto the duct
assembly.
70 Prise the stabiliser over the large
lug on the other side of the duct
assembly.
68 Remove the short screw and
plastic washer from the other side
of the duct.
Remove the pedal assembly.
