Dyson DC24 Service Manual

Fitting notes
Service manual
65
157 The soleplate wheels or axles
can be removed by prising out
of the soleplate.
To fit firmly push into place.
159 With the end released slide the
flicker strip out of the retainers in
the soleplate.
158 If the flicker strip needs replacing
lift the end out of the soleplate
using a thin flat bladed
screwdriver.
Sub assemblies-cleaner head assembly

Dyson DC24 Specifications

General

Type	Upright
Weight	5.4 kg
Cleaner Head	Motorized brush bar
Cyclone Technology	Root Cyclone™ technology
Color	Yellow
Dust Capacity	0.34 L
Special Features	Ball technology
Filter	Lifetime washable filter
