Dyson DC24 - Valve Wheel Replacement

Fitting notes
Service manual
80 Remove the cyclone and bin
assemblies from the product.
Valve wheel replacement
81 Remove the Torx T-8 screw and
washer.
82 Slide the centre of the valve wheel
onto the lug on the end of the
valve hatch and remove.
Fit in reverse.
33
