Dyson DC24 Service Manual

Technical info.
Service manual
03
Wiring Schematic
Live
Neutral
BB Motor
Vac Motor
Switch area
Upright
Switch
Brushbar
Switch
Main On/Off
Switch
PCB Assembly
Vac motor
area
Cleaner Head Assembly
TCO Reset
Button
(normally closed)
J3
J2
J1
Jockey Wheel-
Japanese models only
(normally open)
COMPONENT
Vac motor 8.5 Approx
Cleaner head assembly
Brushbar motor
TERRITORY
RESISTANCE (Ω)
All other components
TEST POINTS
10 to 11
UK/Euro (230/240V)
16 to 17
UK/Euro (230/240V)
UK/Euro (230/240V)
23 to 24
Vac motor 2.4 Approx
Cleaner head assembly
Brushbar motor
US/Can (120V)
Vac motor 2.25 Approx
Cleaner head assembly
Brushbar motor
Japan (100V)
10 to 11
16 to 17
23 to 24
10 to 11
16 to 17
23 to 24
Japan (100V)
Japan (100V)
All 1 Max
725 Approx
400 Approx
420 Approx
120 Approx
135 Approx
85 Approx
US/Can (120V)
US/Can (120V)
Wire colours may vary between territories
1234
5
6
11
10
12
13
15
14
16
18
23
20
24
22
21
17
19
9
7
8

Dyson DC24 Specifications

General

Type	Upright
Weight	5.4 kg
Cleaner Head	Motorized brush bar
Cyclone Technology	Root Cyclone™ technology
Color	Yellow
Dust Capacity	0.34 L
Special Features	Ball technology
Filter	Lifetime washable filter
