Dyson DC24 Service Manual

Fitting notes
Service manual
61
147 Any parts that make up the bleed
valve can be replaced by
unlocking the bleed valve cap
assembly.
148 With the bleed valve cap
unlocked, prise it away from
the cyclone cap assembly.
Remove all parts of the bleed
valve from the cyclone cap
assembly.
Fit in reverse.
149 The cyclone cap assembly can be
replaced by prising it off the
cyclone assembly.
Fit in reverse.
Sub assemblies-cyclone assembly

Dyson DC24 Specifications

General

Type	Upright
Weight	5.4 kg
Cleaner Head	Motorized brush bar
Cyclone Technology	Root Cyclone™ technology
Color	Yellow
Dust Capacity	0.34 L
Special Features	Ball technology
Filter	Lifetime washable filter
