Fitting notes
Service manual
56
136 Slide the end of the outer
insulation of the internal
powercord under the retainer in
the base of the duct assembly.
137 Push the end of the insulation
into the channel.
138 Feed the switch end of the
internal powercord through the
window in the duct assembly.
Duct assembly replacement - fitting
