8.2. Independent Operation from Ambient Air (Type C)
DANGER: The installation location of your condensing boiler and the flue connection of
the flue must comply with the instructions specified by TSE authorized gas companies.
A chimney clamp should be used for each chimney and vertical section transition points, and a
distance of less than 2 m should be left between the two flue clamps. The flue system must be rigidly
fixed to the wall with the flue clamp.
Type C (hermetic) devices are not suitable for outdoor installations. These devices should be installed
inside the building.
In case of gas leakage, it is necessary to vent the installation room according to national and local
requirements, although the room sealed operation boilers are independent of room volume and
ventilation.
DANGER: Do not block the air vents which provide fresh air to the installation room.
The air/flue terminal must be exposed to the external air and allow free passage of air cross it at all
times.
• The minimum acceptable dimensions from the terminal to obstructions an ventilation openings must
obey national and local requirements.
• All horizontally fitted ducts (air/flue) should be fitted 2° or 3° upwards incline to allow condensate
water drain to the boiler.
• The flue ducts are always wet.
• Under cold or excessive humid weather conditions the water vapor inside the
waste gas may condensate while leaving the flue.
8.3. Mounting the Boiler
Having determined the boiler location;
• The points of lock screws of wall bracket and assembly bracket are marked by using the assembly
template inside installation and user’s operating instructions of the device (pages 31-32-33). The
mounting bracket is an optional part.
• After drilling the marked points, wall assembly bracket and assembly bracket are fixed on the wall by
the dowel and lock screws which are inside the packaging of the device.
• Finally, the boiler is hanged on the wall by placing the assembly bracket on the back side of the
boiler on the mounting bracket assembled on the wall.
DANGER: Non-approved combustion air / flue pipes can create a risk of injury. Only use
the manufacturer's original combustion air / flue pipes. It is not appropriate to interfere
with the original chimney kits (cutting, adding, etc.).
DANGER: During installation, the boiler flue set and accessories must be fixed in such a
way as to preserve their impermeability, taking into account the impacts and impacts that
may come from the outside. Otherwise, the CO (carbon monoxide) gas that will leak from
the chimney connections will cause poisoning and pose a life-threatening risk.
INFORMATION
INFORMATION
