61
@IST01530EEJ 019175A0 190411
Turn on the instrument to check the new sensor works correctly through the menu “Sensor Troubleshooting”.
It is normal if a newly installed sensor gives a 'current error': it is necessary to wait some time, so that the sensor
polarization can settle. The table here below shows the minimum settling time for each sensor.
Note:
(1) 2-Hour settling time is required.
(2) 48-Hour settling time is required; should the sensor be equipped with an external polarisation battery, the settling
time is reduced down to 2 hours.
CODE MEASURED GAS POSITION SETTLING TIME
FLEX-Sensor O
2
Cod. AAA32-240
O
2
Oxygen
S1 2 hours
(1)
FLEX-Sensor CO+H
2
Cod. AACSE05
CO
Carbon M onoxi de
S2 2 hours
(1)
FLEX-Sensor NO
Cod. AACSE06
NO
Nitrogen Oxide
S3 48 hours
(2)
FLEX-Sensor NO
2
Cod. AG526-W00
NO
2
Nitrogen Dioxi de
S3 / S4 2 hours
(1)
FLEX-Sensor SO
2
Cod. AD527-W04
SO
2
Sulphur Dioxide
S4 / S3 2 hours
(1)
FLEX-Sensor CO 100.000
Cod. AACSE17
CO
Carbon M onoxi de
S2 2 hours
(1)
FLEX-Sensor CO 20.000
Cod. AACSE18
CO
Carbon M onoxi de
S2 2 hours
(1)
FLEX-Sensor CO+H
2
low range
Cod. AACSE24
CO
Carbon M onoxi de
S2 2 hours
(1)
FLEX-Sensor NO
low range
Cod. AACSE25
NO
Nitrogen Oxide
S3 48 hours
(2)
FLEX-Sensor NO
2
low range
Cod. AACSE26
NO
2
Nitrogen Dioxi de
S3/S4 2 hours
(1)
FLEX-Sensor SO
2
low range
Cod. AACSE28
SO
2
Sulphur Dioxide
S3/S4 2 hours
(1)
9
Reconnect the sensor (See point 3).
10
Close the back door of the sensor compartment again, and tighten screws again (See point 1).
8
Rotate the sensor clockwise until hearing a click (See point 4).
ATTENTION
While rotating the sensor, take care not to apply any pressure onto the printed circuit abov e: apply
pressure onto the plastic body only.
1
