E-Z-GO RXV User Manual

Page xiv
LABELS & PICTOGRAMS
Owner’s Guide
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings.
B
608701 CE VEHICLES
608817
608701
R
F
ON
OFF
I
O
ON
N
F
R
OFF
O
< 14° 25%
< 14° 25%
ON
OFF
I
O
R F
F
R
OFF
O
ON
N
ON
N
F
R
OFF
O
R
F
ON
OFF
I
O
608817
MAXIMUM RAMP
OR HILL
MAXIMUM CROSS
RAMP OR HILL
OPERATE FROM
DRIVER SIDE ONLY
DO NOT STAND UP
AND KEEP ENTIRE
BODY INSIDE
VEHICLE
DO NOT DRIVE
ON HIGHWAY
DO NOT OPERATE
IF USING DRUGS
OR ALCOHOL
READ THE MANUAL
OPERATE ACCORDING
TO LOCAL LAWS AND
REGULATIONS
USE CAUTION IN
BAD WEATHER
FORWARD OPERATION
* TURN KEY TO ‘ON’
* MOVE DIRECTION
SELECTOR TO ‘F’
* PRESS ACCELERATOR
PEDAL GENTLY
REVERSE OPERATION
* TURN KEY TO ‘ON’
* MOVE DIRECTION
SELECTOR TO ‘R’
* PRESS ACCELERATOR
PEDAL GENTLTY
PARK VEHICLE
* MOVE DIRECTION
SELECTOR TO ‘F’
* TURN KEY TO ‘OFF’
* APPLY PARKING
BRAKE
GASOLINE
VEHICLES
FORWARD OPERATION
* TURN KEY TO ‘F’
* PRESS ACCELERATOR
PEDAL GENTLY
REVERSE OPERATION
* TURN KEY TO ‘R’
* GENTLY PRESS
ACCELERATOR
PEDAL
PARK VEHICLE
* TURN KEY
TO ‘OFF’
ELECTRIC
VEHICLES
HANDLE UP
BRAKE IS ON
PUSH HANDLE
DOWN AND
HOLD TO
RELEASE BRAKE
READ THE
MANUAL
REPLACEMENT
AVAILABLE AT
www.ezgo.com
WARNING: WHEN
BRAKE IS OFF
VEHICLE MAY MOVE
WHEN STOPPED
ON A SLOPE

E-Z-GO RXV Specifications

General

Model	RXV
Category	Golf Cars
Seating Capacity	2
Power Source	Electric
Motor Type	AC Induction
Battery Voltage	48V
Steering	Self-Compensating Rack and Pinion
Ground Clearance	4.5 in
Front Suspension	Independent
Frame	Welded steel with DuraShield powder coat
Body	Plastic
Tires	18 x 8.5-8
Dimensions	47.0 in
Wheelbase	65.7 in
Vehicle Load Capacity	800 lb
Top Speed	19 mph
Batteries	6 x 8V
