EAE EE-6435B.WF - Page 35

Installation, Operation and Parts Manual
EE-6435B .WF
35
POS.
Code
Name
Specification
Qty
T
320101075
Transformer
JBK3-400VA 400V-24V
1
SQ1,SQ2,SQ7
320301009
Limit switch 8104
TZ-8104
3
SQ3-SQ6
320301011
Limit switch 8108
TZ8108
4
SA
320303010
Option Switch (binary)
AR22PR-222B
1
QS
320304001
Power switch
LW26GS-20/04
1
SB2
320401017
Button
AR22F0R-20-W
1
