EAE EE-6435B.WF - Page 36

Installation, Operation and Parts Manual
EE-6435B .WF
36
POS.
Code
Name
Specification
Qty
SB
320402002
Emergency stop
XB2BS542C
1
KA2
320601001
Relay
HH54P-L/DC24V（MY4NJ)
1
KA1
320601007
Relay
HH64P-L/DC24V-10A（LY4NJ）
1
320601010
Relay holder
PTF-14A-E
1
320601011
Relay holder
PYF-14A-E
2
320601018
Relay fixer
4
KT
320602001
Time relay
ST6P-2AC24V,5S
1
320602006
Time relay holder
PYF-08A-E
1
320602007
Time relay fixer
2
QF
320801001
Circuit breaker
DZ47-63C16/3P
1
QF1
320803003
Circuit breaker
DZ47-63C3/1P
1
QF2
320803006
Circuit breaker
DZ47-63C10/1P
1
KM
320901001
AC contactor
CJX2-1210/AC24
1
C
321001004
Capacitor
4700UF/50V
1
VD
321002001
Bridge rectifier
KBPC5A-35A
1
HL
321201001
Power indicator
AD17-22G-AC/DC24(RDD6-22D/31-AC/DC24)
1
FA
321202001
Alarm buzzer
AD17-22SM/AC/DC24(RDD16-22SM/AC/DC24)
1
YA1-YA4
330310007
Electromagnet
6435B-A14 (MQB3-10-20/AC24V)
4
SB1,SB3
320401019
Button
AR22F0R-31-W
2
SB4
320401034
Button
NP9（2NO+2NC）
1
