EAE EE-6435B.WF - Page 41

Installation, Operation and Parts Manual
EE-6435B .WF
41
Pos.
CODE
Name
QTY
NOTE
17
410270051D
Safety block B1
2
18
410270061
Adjustable rod A
4
19
410270660
Spring
4
20
330310007
Electromagnet
4
21
410270601
Adjustable post
4
22
410270151
Adjustable chip
4
23
410270011
Slider holder
8
24
420270010
Slider
8
25
612027004
Safety block A2
2
26
410270121D
Safety block B2
2
27
420270040
Protection cover
4
29
321204018
Terminal box
2
30
202101009
Cross socket cap head screw M4*14
2
31
614027301
Holder B for plastic chain
1
32
420270150
Oil hose protection ring
2
34
205101001
Lubrication bearing
4
35
203101005
Hex nut M8
12
36
320301011
Limit switch 8108
4
37
204301007
Circlip φ20
16
38
204301005
Circlip φ16
12
39
204301009
Circlip φ25
8
40
204101005
Flat washer φ8
36
41
202103012
Cross socket flat head screw M6*12
4
42
202110004
Hex socket button head screw M 8*12
32
43
202111027
Hex socket flat head screw M5*16
8
44
202110010
Hex socket button head screw M 4*16
8
45
202111007
Hex socket flat head screw M 8*20
8
46
202109022
Hex socket cylinder head screw M 6*25
6
47
203101004
Hex nut M6
12
48
202110003
Hex socket button head screw M6*12
4
GB/T 70
49
202109026
Hex socket cylinder head screw M6*60
4
GB/T 70
52
203101004
Hex nut M6
8
53
203101007
Hex nut M12
4
