Com port wiring to transmit NMEA information
to a Uniden or similar VHF radio or other device.
Twist the appropriate wires together, making sure that the exposed
ends make good contact. Secure the wire ends with wire nuts, then
wrap each wire nut securely with electrical tape to protect against
moisture, as shown in the figure on the right.
After taping the wire ends individually, wrap the entire connection
with electrical tape as shown. This will help protect from moisture and
prevent the wires from breaking contact.
Ground/Shield or NMEA –
To Uniden
radio or othe
r
device
o
m port to
C
uda 250
Y
ellow (Transmit)
NMEA Wire (Receive) or NMEA +
Shield (Ground)
