37
Mount the sonar: slide the unit onto the bracket from above.
Adjust viewing angle: use one hand to press and release the spring-
loaded ratchets while you move the unit with the other hand. An op-
tional GBSA-3 swivel base is shown with the quick release bracket.
Bracket front
Depress
ratchets to
release.
Swivel base
