Eagle new IDA - Setting Screen

24
Histogram window
Automatically opens when loading or capturing an
image (configurable in the options menu)
Tooth checkbox
Used to check the tooth (teeth) showed in the
image.
Accompany "delete" button to undo checking.
Setting.
Allows the access to the parameters of your
computer (format and file path of database of
images, downloads)
Help
Shows tutorial on how to perform an acquisition
Setting screen
To set the application, press the icon . The following screen will appear.
