5. Maintenance & Troubleshooting
5.1 Maintenance
TURN POWER SWITCH TO THE OFF POSITION AND DISCONNECT FROM POWER
SUPPLY PRIOR TO PERFORMING ANY MAINTENANCE OR REPAIRS TO THE
MACHINE
Regular maintenance will prolong machine life and lower the chance of malfunctions.
1. Check that all connections are tight.
2. Ensure that all screws, bolts and other mechanical connections are tight.
3. Lubricate moving parts.
a. Chain (Wheel)
b. Screw Rod
c. Guide Rail (Slide Block)
d. Guide Rod
4. Clean tape cutting blade.
5.2 Troubleshooting
Case does not seal well
Adhesive tape is not centered on
the box.
Adjust the tape alignment.
Adhesive tape does not cut
properly
The blade is too high, will also
case scrape marks on the carton
Lower cutting blade
The blade is too low
Raise cutting blade
Cutter force is too low
Adjust the tension of the cutter
force spring on the blade shelf.
Adhesive tape does not adhere to
the carton
Unidirectional rubber wheel is
broken
Replace
The head of back adhesive tape is
wiping unevenly.
Adjust the speed of the
press/wipe belt cylinder.
Adhesive tape is wrinkled.
Adjust the force of extension
spring of front rubber wheel.
Carton does not feed properly
The spacing of the catch pin is too
narrow.
Adjust catch spin spacing.
Irregularly shaped carton
-
Suction feed system malfunction
Check for defects or damage to
the suction disks. Replace as
needed.
