Eagle T20CF - Control Panel Operation

- 8 -
4. Operation
4.4 Feeding the Adhesive Tape
Guide tape roller
Rubber roller
Adhesive tape core adjustment button
Adhesive tape
Adhesive tape
Press tape board
Guide tape board
Unidirectional
lozenge pattern roller
Guide tape roller
4.5 Control Panel Operation
Before operating the machine, the operator should review the features and functions of every switch to
ensure the correct and safe operation of the machine.
1. Power Indicator
2. Power Switch
3. LCD Display Screen
4. Emergency Stop Button
5. Start Button
6. Stop Button
7. Reset Button
5
3
7
1
6
4
2
