Eagle T20CF - Left & Right Cover Folder

- 32 -
6. Machine Parts & Illustrations
6.11 Left & Right Cover Folder Assembly (continued)
Description
Part Number
Qty
1
Left / Right Folding Base
CF-20TX-150
1
2
Bearing Base Padding Block
CF-20TX-136
2
3
Conveyor Gear
CF-20TX-135
2
4
Bearing Base
UCPA 204
4
5
Clamping Block
CF-20TX-134
2
6
Left / Right Folding Rod
CF-20TX-144
2
7
Folding Rod Closure Head
CF-20TX-141
4
8
Folding Rod Cylinder Back Shaft
CF-20TX-151
1
9
Back Base Block
CF-20TX-145
2
10
Back Base Plate
Cf-20TX-146
1
11
Cylinder
SC50x80-s
1
12
Cylinder Pearl Eye Joint
SC50
1
13
Swing Block
CF-20TX-137
1
14
Folding Rod Cylinder Front Shaft
CF-20TX-138
1
15
Folding Rod Moving Shaft
CF-20TX-140
1
16
Folding Rod Shaft
CF-20TX-139
1
