Eagle T20CF - Vacuum-Assisted Carton Placer

- 27 -
6. Machine Parts & Illustrations
6.9 Vacuum-Assisted Carton Placer Assembly (continued)
Description
Part Number
Qty
1
Large Pulley
CF-20TX-127
2
2
Connecting Rod Assembly
CF-20TX-132
1
3
Small Pulley
CF-20TX-128
1
4
Pulley Shaft
Cf-20TX-133
1
5
Linear Sliding Base I
CF-01-04-047.1
1
6
Width Guide Rod
CF-20TX-94
1
7
Guide Rod L Plate
CF-20TX-93
2
8
Vacuum Disc Upright Sliding Rod
CF-20TX-92
1
9
Vacuum Disc Cap
CF-20TX-18
8
10
Hand Wheel
1
11
Vacuum Disc Sliding Bush
CF-20TX-17
4
12
Sliding Base
CF-01-04-039
2
13
Vacuum Disc
ESS-80-GT-G1/4
4
14
Spring
4
15
Sliding Rod
CF-20TX-20
4
16
Vacuum Disc Installation Plate
CF-20TX-37
4
17
Width Limit Clamp Block
CF-20TX-147
2
18
Width Limit Clamp Block I
CF-20TX-148
2
19
Width Cushion Ring
CF-20TX-149
2
20
Width Guide Rod I
CF-20TX-95
2
21
Vacuum Disc Level Sliding Rod
CF-20TX-89
1
22
Sliding Rod Base Plate
CF-20TX-79
1
23
Sliding Rod Connecting Plate
CF-20TX-199
1
24
Width Linear Base
CF-20TX-73
1
25
Cushion Installation Base
CF-20TX-77
1
26
Oil Pressure Bumper
AC-2020-2
1
27
Width Limit Sliding Base
CF-20TX-70
2
28
Width Sliding Bushing
CF-20TX-71
2
29
Width Screw Rod
CF-20TX-80
1
30
Bearing
SBLF 202
1
31
Handle
1
32
Cylinder Accessory
SC50-CB
1
33
Cylinder
SC50x80-S
1
34
Vacuum Installation Plate
CF-01-04-146
1
35
Linear Bearing
LM25UU
6
36
Cylinder Pear Eye Joint
SC50
1
37
Width Linear Base
CF-20TX-74
1
38
Connecting Rod Shaft Base
CF-20TX-126
1
39
Bearing
6005
2
