Eagle T20CF - Blocking Pin & Press Plate

- 30 -
6. Machine Parts & Illustrations
6.10 Blocking Pin & Press Plate Assembly (continued)
Description
Part Number
Qty
1
Lifting Body
FJ-1A-30
2
2
Upright Pose Roller Wheel
FJ-1A-105
8
3
Screw Nut
FJ-1A-106
2
4
Supporting Plate
FJ-1A-69
2
5
Bearing
61905
2
6
Lifting Screw Rod
FJ-1A-71
1
7
Handle
1
8
Carton Rack Upper Block
CF-20TX-100
2
9
Blocking Pin
CF-20TX-98
1
10
Hand Wheel
3
11
Carton Sliding Base Block
CF-20TX-97
3
12
Pin Rack Block
CF-20TX-198
1
13
Pin Rack Supporting Pipe Block
CF-20TX-193
1
14
Lifting Screw Rod
FJ-1A-70
1
15
Leveling Arm Assembly
CF-20TX-186
1
16
Press Plate
CF-20TX-189
1
