Eagle T20CF - Carton Sealer - Front Roller

- 34 -
6. Machine Parts & Illustrations
6.12 Carton Sealer - Front Roller Assembly (continued)
Description
Part Number
Qty
1
Bracket
FJ-01-09
1
2
Front & Back Roller Shaft
FJ-00-10
1
3
One-Way Roller Shaft
FJ-E-38-01
1
4
Front Rubber Roller Wheel
FJ-E-41-01
1
5
Front Roller Wheel Press Spring
FJ-H-02
1
6
Front Roller Wheel Washer
FJ-04-06
1
7
Cross Flat Trench Screw
M4x12
1
8
Cross Flat Head Screw
M5x15
1
9
Press Tape Board Assembly
1
10
Hold-Down Unit
1
11
Front Claw Fulcrum
FJ-00-09
1
12
Guide Tape Board Spacer
FJ-02-02
2
13
Bearing
6900 (1080900)
1
14
Front Claw
FJ-50-00
1
15
Guide Tape Wheel Assembly
1
16
Tape Wheel Knurling Spacer Bushing
FJ-02-11
1
17
Bearing
688Z (208088)
1
18
Bearing
HK2020
1
19
Guide Tape Board Roller Wheel
FJ-02-10
1
20
Tension Spring Shaft
FJ-00-11
1
21
Front Claw Fulcrum
FJ-00-09
1
22
Guide Tape Board Tension Spring
FJ-H-00
1
