6. Machine Parts & Illustrations
6.3 Carton Storage Table Assembly (continued)
Description
Part Number
Qty
1
Drag Hook Base
CF-20TX-159
1
2
Drag Hook
CF-20TX-60
1
3
Guide Carton Board Filler Strip
CF-20TX-57
1
4
Guide Carton Board
CF-20TX-56
2
5
Send Carton Guide Rod
CF-20TX-58
2
6
Baring Base
SBLF 202
4
7
Work Table Screw Rod I
CF-20TX-62
1
8
Screw Nut
CF-20T-H-01
2
9
Chain Wheel
FJ-MA-60
2
10
Handle
-
1
11
Chain
06B
12
Work Table Screw Rod
CF-20TX-61
1
13
Fixing Block Backing Board
CF-20TX-51
2
14
Hand Wheel
-
2
15
Send Carton Board Fixing
CF-20TX-50
2
16
Push Carton Board
CF-20TX-63
1
17
Handle
-
1
18
Send Carton Stand Rod Assembly
CF-20TX-53
1
19
Send Carton Linear Base
CF-20TX-48
1
20
Worktable
CF-20TX-68
1
21
Linear Bearing
LM20UU
2
