Eagle T20CF - Page 20

- 20 -
6. Machine Parts & Illustrations
6.5 Back Cover Carton Fold & Push Device (continued)
Description
Part Number
Qty
1
Pearl Eye Joint
SC40
2
2
Linear Bearing
LM25UU
4
3
Linear Sliding Base
CF-20TX-38
2
4
Linear Filling Strip
CF-20TX-21
4
5
Push Carton Cylinder Front Shaft
CF-20TX-28
1
6
Push Carton Rod Combination
CF-20TX-33
1
7
Molding Bent Rod
CF-20TX-36
1
8
Folding Pendulum
CF-20T-G-14
1
9
Folding Cramp Arm
CF-01-04-21.1
1
10
Pendulum Shaft
CF-01-04-25.4
1
11
Bearing
61904
2
12
Back Folding Cover Base
CF-20TX-27
1
13
Folding Front & Back Swing Arm
CF-20T-09
1
14
Folding Back Cylinder End Shaft
CF-01-04-198.1
1
15
Cylinder
SC40x80-S
1
16
Length Base Plate
CF-20TX-46
1
17
Linear Sliding Base II
CF-01-04-047.3
2
18
Slide Bushing
CF-20TX-178
4
19
Length Guide Rod
CF-20TX-47
2
20
Handle
1
21
Bearing Base
SBLF202
1
22
Cylinder
SC40x250-S
1
23
Push Carton Cylinder Base
CF-20TX-24
1
24
Length Screw Nut
CF-20TX-45
1
25
Length Screw Rod
CF-20TX-81
1
