Auto Fan Status (fan in auto
mode)
0..1
Off - On
FUNCTION CODE 04 - READ INPUT REGISTERS (Add 30,000 for Modicon
Addressing)
100
Built-In Temperature
Measurement
Signed 16
-400...3020
-40.0...150.0°C
(-40.0..302.0°F)
101
Resistive Input 1 Measurement
Signed 16
-400...3020
-40.0...150.0°C
(-40.0..302.0°F)
102
Resistive Input 2 Measurement
Signed 16
-400...3020
-40.0...150.0°C
(-40.0..302.0°F)
103
Current Calculated Setpoint (°C)
Signed 16
-400...3020
-40.0...150.0°C
(-40.0..302.0°F)
104
Interface Current Mode
Unsigned 16
0..3
0 = Comfort
1 = OFF
2 = Party (Boost) Mode
105
Relative Humidity Measurement
(with RH option)
Unsigned 16
0..1000
0..100.0 %rH
106
Alarm State
Unsigned 16
0..256
Bit 0 = Internal NTC (1)
Bit 1 = RI1 (2)
Bit 2 = RI2 (4)
Bit 3 = Humidity sensor
(8)
Bit 4 = DI1 (16)
Bit 5 = DI2 (N/A)
Bit 6 = Time Lost (64)
107
Discrete Input Registers (Bit 0 =
DI1, Bit1 = Relay, Bit 2 = Holiday
etc.)
Unsigned 16
0..65,535
N/A
108
N/A
109
N/A
110
N/A
111
Current Fan Speed
Unsigned 16
0..6
0..6
112
Mode Icon Status
Unsigned 16
0..3
0 = Auto
1 = Heating
2 = Cooling
3 = Ventilation Fan
200
Firmware Version
Unsigned 16
N/A
N/A
FUNCTION CODE 03 - READ HOLDING REGISTERS (For Modicon Addressing Add
40,000)
FUNCTION CODE 06 - WRITE SINGLE HOLDING REGISTER
FUNCTION CODE 16 - WRITE MULTIPLE HOLDING REGISTERS
100
Nominal Setpoint
Unsigned 16
0...990
0...999.0 (Default 21.0)
(°C/°F/%)
101
Setpoint Unit
Unsigned 16
0..1
0 = Temperature
(Default)
1 = Percentage
102
Sensor 3 Source
Unsigned 16
0..1
0 = Built-In Sensor
(Default)
1 = Network Sensor
103
Sensor 3 Network Temperature
Signed 16
-580...1220
-58.0…122.0°C/°F
(Default 0.0)
104
Minimum Setpoint
Unsigned 16
0...990
0.0...99.9°C/°F/%
(Default 14°C)
105
Maximum Setpoint
Unsigned 16
0...990
0.0...99.9°C/°F/%
(Default 30°C)
106
Colour Ring Mode
Unsigned 16
0..10
0 = White
1 = Red
2 = Blue
