EasyIO SH-TSX - Technical Data

SH-TSX Product Manual - © EasyIO / www.easyio.eu
6
Technical data
Power Supply
Power Supply
Models -24: 24VAC/DC -10%/+15%, max.
80mA
Display
Touchscreen
3.5" Backlit Touchscreen, 320 x 480 pixels,
255k colours
Signal Outputs
Relay Output
1 x 7A (res.) / 2.2A (inductive) at 230Vac /
1.3A (inductive) at 115Vac
Signal Inputs
Built-In Sensor
0..50°C (32..122°F) ±0.5°C @ 25°C
External Sensor Inputs
2 x External NTC10K3 Sensor
Digital Input
1 x Digital Input, Volt-Free Contact, Impedance
<1KOhm
Optional Sensing
Characteristics
Humidity (RH Models)
Range
Accuracy
0..100%rH
±2% rH (within 20..80% rh)
Communication
Modbus (-MOD models)
Protocol
Interface
Addressing
Communication
Modbus RTU
RS485; maximum 63 devices
1..247 via Touchscreen
9k6/19k2/38k4/57k6/76k8 Baud; Parity
None/Even/Odd, 1 or 2 Stop Bits (adjustable
through Touchscreen)
BACnet (-BAC models)
Protocol
Interface
MAC Addressing
Device ID
Communication
BACnet MS/TP
RS485; maximum 63 devices
0..127 via Touchscreen
Default 651000 + MAC Address, Adjustable
9k6/19k2/38k4/57k6/76k8 Baud; Parity
None/Even/Odd, 1 or 2 Stop Bits (adjustable
through Touchscreen)
Connections
Terminal Connections
(Relay & Power Supply)
Solid and Stranded Cable
Maximum Size: Solid; 0.05-2.5mm2, Stranded:
0.05-1.50mm2
Rising Clamp: Size 2.5 x 2.2mm
Terminal Connections (Low
Voltage Terminals)
Solid and Stranded Cable; 90° Angle for Wiring
Maximum Size: 0.05 to 1.5mm2 (EN ISO) / 14
to 30 AWG (UL)
Rising Clamp: Size 2.5 x 1.9mm
Environmental
Conditions
Operating
Temperature
Humidity
0°C...+50°C (32..122°F)
0...95%rh (non-cond.)
Storage
Temperature
Humidity
-30°C...+70°C (-22..158°F)
0...95%rh (non-cond.)
Standards
CE Conformity
CE Directive 2004/108/EC (EMC), 2006/95/EC
(LVD)
EN61000-6-3: 2001 (Generic Emission)
EN61000-6-1: 2001 (Generic Immunity)
Degree of Protection
IP20
Housing
Housing Material
Polycarbonate Plastics, Self Extinguishing, (V0
rated), Silver and Black
Mounting
Wall or Junction Box Mounting
Dimensions
W88 x H112 x D43mm; Flush: W88 x H112 x
D14.5mm
Weight
220g
