Who-Has
Yes
DM-DOB-B
I-Have
Yes
DeviceCommunicationControl
Yes
DM-DCC-B
TimeSynchronisation
Yes
DM-TS-B
BACnet Standard Object Types Supported
No dynamic Creation or Deletion supported. Objects, and object instances, are assigned to fixed
functions within the proprietary control application of the product as follows
Object
Number of Instances
Instance Assignments
Device Object
1
Analog Input
6
AI(0) – Sensor 3 (Built-in Sensor)
AI(1) – Setpoint (Calculated)
AI(2) – Humidity Measurement
AI(3) – Sensor 1 (RI1)
AI(4) – Sensor 2 (RI2)
AI(5) – CO2 Measurement
Analog Value
8
AV(0) – Nominal Setpoint
AV(1) – Sensor 1 Temp
AV(2) – Sensor 2 Temp
AV(3) – Sensor 3 Temp 
AV(4) – Brightness
AV(5) – Y1 Output
AV(6) – Y2 Output
AV(7) – Y3 Output
Binary Input
5
BI(0) – Digital Input (DI1)
BI(1) – Boost (Party Mode) Status
BI(2) – NA
BI(3) – NA
BI(4) – Auto Fan Status
Binary Output
9
BO(0) – Relay
BO(1) - OFF Status *1
BO(2) - ECO Status *1
BO(3) – Lights. *2
BO(4) – AC. *2
BO(5) – Lock *1
BO(6) – Frost Icon
BO(7) – Non Volatile Update (updates
setpoints/configuration parameters)
BO(8) – Boost Icon
MultiState Value
7
MSV(0) – Ring Colour [Read/Write]
(1=White, 2=Red, 3=Blue, 4=Green, 5=Orange,
6=Yellow, 7=Magenta, 8=Cyan, 9=Sensor1,
10=Sensor2, 11=Sensor3)
MSV(1) – ModeIconOverride [Read/Write]
(1=Auto, 2=Heating, 3=Cooling, 4=Fan, 5=None) *3
MSV(2) – FanAutoSpeed [Read/Write]
1..7 (corresponding speeds 0..6). *4
MSV(3) – Device Mode Status [Read only]
(1=Comfort, 3=OFF, 4=Boost)
MSV(4) – Alarm Status [Read only]
(Add 1 to bit values)
Bit 0 – Internal NTC (1)
Bit 1 – RI1 (2)
Bit 2 – RI2 (4)
