EasyIO SH-TSX - Device Object Properties

SH-TSX Product Manual - © EasyIO / www.easyio.eu
29
Bit 3 – Humidity Sensor (8)
Bit 4 – DI1 (16)
Bit 5 – DI2 (Not Applicable)
Bit 6 – Time Lost (64)
MSV(5) – Mode Icon Status [Read only]
(1=Auto, 2=Heating, 3=Cooling, 4=Fan)
MSV(6) – Fan Speed Status [Read only]
1..7 (corresponding speeds 0..6) *4
Note 1: If the BACnet object state is overriden locally (e.g. OFF/ECO/Lock locally cancelled), then to
read the device status in the Present Value field, set all priority inputs to ’null’.
Note 2: Light and AC icons can be locally overridden only if the all Priority inputs are set to ’null’.
Note 3: Set to ’5=none’ to allow users to change the Mode through the screen.
Note 4: The maximum number depends on the selected Fan Speed Mode. E.g if 3-speed is selected,
then the range is 1..4 (corresponding speeds 0..3).
Device Object Properties
Property Name/ID
Attributes
Range
Default
Object Identifier
R/W
20
Object Name
R/W
32
Characters
Max
Concatenation of product type and MAC
address
Object Type
R
Device
System Status
R
STATUS_OPERATIONAL
Vendor Name
R
EasyIO
Vendor Identifier
651
Model Name
R
SH-TSX
Protocol Version
R
1
Protocol Revision
R
10
Max APDU Length
R
480
Segmentation Support
R
No
APDU Timeout
R
6000 ms
Number APDU Retries
R
3
MaxMaster
R
127
Max_Info_Frames
R
1
Database Revision
R
0
