5.3 Single UPS Unit System Oneline Configurations
The system oneline drawings in this section show the simplified internal structure of the UPS, battery supply,
and basic maintenance bypass.
Oneline Drawing UPS Model
Voltage
System TypeInput Output
See Figure 5-5 9E-40
9E–60/40
9E–60/60
208/220 208/220 Single Reverse Transfer UPS
with Internal Battery
See Figure 5-6 9E-40
9E–60/40
9E–60/60
208/220 208/220 Single Reverse Transfer UPS
with External Battery
