Page #30 background image
5 Anhang
5.2 Sicherheitstechnische Funktionen
26 Elektronischer Motorstarter EMS/EMS Electronic Motor Starter 04/15 MN03407009Z-DE/EN www.eaton.com
5.2 Sicherheitstechnische Funktionen
Systembedingungen Einheit EMS-…-ROS-… EMS-…-DOS-…
Datenbank für Ausfallraten SN 29500 SN 29500
Systemtyp Typ B, bestehend aus Subsystemen Typ B, bestehend aus Subsystemen
Angewandte Norm IEC 61508 IEC 61508
Beta-Faktor % 1 1
MTTF (bei Umgebungstemperatur 40 °C) a 35,7 35,7
Sicheres Abschalten
(nur für EMS-…-S-…-Geräte
Umgebungstemperatur °C 40 40
MTTF
d
a 420 421
Abschaltzeit ms 40 (EMS-…-2,4-…)
80 (EMS-…-9-…)
40 (EMS-…-2,4-…)
80 (EMS-…-9-…)
λ
sd
[FIT] 49 47
λ
su
[FIT] 1818 1582
λ
dd
[FIT] 269 269
λ
du
[FIT] 2,7 2,4
SFF % 99,8 99,8
DCS % 2,6 2,9
DC % 99 99
PFH 1/h 2,7 x 10
-9
2,4 x 10
-9
Sicherheitslevel
gemäß IEC 61508-1 SIL 3 SIL 3
gemäß ISO 13849-1 Kat. 3 PL e Kat. 3 PL e
gemäß EN 954-1
Kat. 3 Kat. 3
Motorschutz
Thermische Überlast (nach EN 60947-4-2
Auslöseklassen 10 bzw. 10A)
Umgebungstemperatur °C 40 40
MTTFd a 316 316
λ
sd
[FIT] 0 0
λ
su
[FIT] 1731 1550
λ
dd
[FIT] 314 314
λ
du
[FIT] 47,2 47,2
SFF % 97,7 97,9
DC % 86,9 86,9
Sicherheitslevel
gemäß IEC 61508-1 SIL 2 SIL 2
Für darüber hinausgehende Temperaturen sind die sicherheits-
technischen Daten bei dem Hersteller anzufragen.
