Eaton EX RT7 - Rear Panels; Power Module EX RT 5;7;11; Battery Module EX RT EXB 7;11

Page 6 - 34007724EN/AD
BY
PASS
NORMAL
1. Presentation
1.2 Rear panels
Slot for communication cards.
Communication port by relays.
Remote Emergency Power Off communication port (REPO).
Connectors for automatic detection of battery module(s).
RS232 communications port.
Battery module connectors (to the UPS or to other battery
modules).
Manual Bypass switch.
Output terminal block.
Normal AC source circuit-breaker.
Normal AC source terminal block.
Bypass AC source terminal block.
Power module EX RT 5/7/11
Battery module EX RT EXB 7/11
Connectors for automatic detection of battery module(s).
Battery module connectors (to the UPS or to other battery
modules).
Battery circuit breaker.
