Eaton i-on30R User Manual

Introduction
Page 6
i-kp01
KEY-K01
KEY-KP01
KEY-KPZ01
KEY-RKPZ
KEY-FKPZ (similar
layout)
Figure 2. Keypad features (see the following sections)
LCD display
("1" on Figure 2.)
The LCD display shows messages and prompts to guide you through
actions such as setting, unsetting, acknowledging alarms and using the
user options.
When the system is idle (either while set or unset), the display shows the
“standby screen”. For example:


(The top line may show a name other than the control unit's model name.)
A
B
C
D
1
4 ghi
7 pqrs
* 0 #
2 abc
5 jkl
3 def
6 mno
8 tuv 9 wxyz
2
3
5
4
6
1
