Rating data on the nameplate
11
Rating data on the nameplate
The device specific rating data of the M-Max
TM
is shown on the
nameplate on the side of the device and on the rear of the control
signal terminal cover.
The inscription of the nameplates has the following meaning
(example):
Label Meaning
MMX34AA3D3F0-0 Part no.:
MMX = frequency inverter of the M-Max
TM
series
3 = Three-phase power connection
4 = 400 V voltage category
AA = Instance (Software version A and
alphanumerical display)
3D3 = 3.3 A rated operational current
(3-decimal-3)
F = Integrated radio interference
suppression filter
0 = IP20 protection type
0 = No integrated optional assembly
Input
Power connection rating:
Three-phase AC voltage (U
e
3~ AC),
380 - 480 V voltage, 50/60 Hz frequency,
input phase current (4.0 A)
Output Load side (motor) rating:
Three-phase AC voltage (0 - U
e
), output
phase current (3.3 A), output frequency
(0 - 320 Hz)
Power Assigned motor rating.
1.1 kW at 400 V/1.5 HP at 460 V for a
four-pole internally-cooled or surface-
cooled three-phase asynchronous motor.
(1500 min
-1
at 50 Hz/ 1800 rpm at 60 Hz)
S/N Serial number
Frequency inverter is an electrical appa-
ratus.
Read the manual (in this case
AWB8230-1603) before making any
electrical connections and commissioning.
IP 20/Open type
Protection type of the housing: IP 20, UL
(cUL) Open type.
12W10
manufacturing date
Week 12 of 2010.
