Parameters
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 73
Digital Inputs, continued
The binary connection of three digital inputs enable calling seven fixed
frequencies (eight fixed frequencies if parameter P6.2 = 0 is set)
The limitation of the fixed frequencies is done based on parameters
P6.3 (minimum frequency) and P6.4 (maximum frequency)
The switch between the individual fixed frequencies is done with the
acceleration time and deceleration times in P6.5 and P6.6
Function to Control Signal Terminals
PNU ID
Access
RUN Value/Range Description
Factory Setting
(P1.3)
P3.6 406 — Ext. fault open (N/C) 0
Like P3.2 Allocation of the function to control signal terminals
Error message when switching off or interrupting
(wire-breakage-safe) the applied control voltage (+24V) from
the assigned control signal terminal (DI1 to DI6)
P3.7 414 — Fault reset 5
Like P3.2 Allocation of the function to control signal terminals
Acknowledges a displayed error message (Reset) when
switching on +24V on the assigned control signal terminal
(DI1 to DI6)
P3.8 407 — Run enable 0
Like P3.2 Allocation of the function to control signal terminals
Rotational direction-independent start release when switching
on +24V on the assigned control signal terminal (DI1 to DI6)
P3.9 419 — Fixed frequency, binary value B0 3
Like P3.2 Allocation of the function to control signal terminals
per table below
P3.10 420 — Fixed frequency, binary value B1 4
Like P3.2 Allocation of the function to control signal terminals
per table below
P3.11 421 — Fixed frequency, binary value B2 0
Like P3.2 Allocation of the function to control signal terminals
per table below
Input (Binary) Fixed Frequency
B0 B1 B2 (Factory setting)
FF0, P10.1 = 6 Hz, only if P6.2 = 0
X FF1, P10.2 = 12 Hz
X FF2, P10.3 = 18 Hz
X X FF3, P10.4 = 24 Hz
X FF4, P10.5 = 30 Hz
X X FF5, P10.6 = 36 Hz
X X FF6, P10.7 = 48 Hz
X X X FF7, P10.8 = 60 Hz
